What is Screw Conveyor Flow Rate Calculator?
Screw Conveyor Flow Rate Calculator is an online tool used to estimate the flow rate of a screw conveyor based on input parameters such as diameter, pitch, RPM, loading ratio, density and inclination factor.
This calculator utilizes the Screw Conveyor Flow Rate Formula, which estimates the mass flow rate of material that can be conveyed via screw conveyor.
This tool provides the mass flow rate in kilograms per hour (kg/hr). It’s useful for engineers and designers who are designing screw conveyor systems to determine the required material flow rate that will be conveyed.
How to Calculate Screw Conveyor Flow Rate?
Steps to Calculate Screw Conveyor Flow Rate:
- Determine the diameter and pitch of the screw conveyor.
- Determine the RPM of the screw conveyor.
- Determine the loading ratio of the screw conveyor.
- Determine the loose material density.
- Determine the inclination factor.
- Use the Screw Conveyor Flow Rate Formula to calculate the flow rate.
Q = 60 * pi/4 * D^2 * S * N * a * d * C
Where
- Q is the mass flow rate (kg/hr)
- D is the diameter of the screw (m)
- S is the screw pitch (m)
- N is the RPM a is the loading ratio
- d is the loose material density (kg/m^3)
- C is the inclination factor
Example:
Let’s say we need to calculate the flow rate of a screw conveyor with a diameter of 0.5 meters and a pitch of 0.3 meters, operating at 120 RPM, with a loading ratio of 0.7, loose material density of 800 kg/m^3, and an inclination factor of 1.2.
Using the formula above, we have:
Q = 60 * pi/4 * D^2 * S * N * a * d * C
Q = 60 * 3.14/4 * 0.5^2 * 0.3 * 120 * 0.7 * 800 * 1.2
Q = 47664 kg/hr
Therefore, the flow rate of this screw conveyor is 47664 kg/hr.
