Capacitor Charge Calculator

The Capacitor Charge Calculator computes capacitor charge from capacitance and voltage, and inversely solves for capacitance or voltage when charge is known.

What this calculator does, and what it does not: it computes the static charge a capacitor holds at a given voltage with Q = C × V, solves for whichever of charge, capacitance, or voltage you leave blank, and reports the stored energy E = ½ × C × V². It does not work out how long a capacitor takes to charge, or how the voltage rises while a circuit is switched on, because that timing depends on the rest of the circuit and is outside this tool’s scope.

Capacitor Charge Calculator Explained

A capacitor stores electric charge by separating positive and negative charges on two plates. The amount of charge depends on the capacitance and the voltage across the device. In simple terms, more capacitance or higher voltage means more stored charge.

This calculator works with the steady relationship between charge, capacitance, and voltage. Enter any two of those three values and it returns the third using Q = C × V. It also reports the energy stored in the capacitor at that voltage.

Under the hood the tool rearranges a single equation. For charge it multiplies capacitance by voltage; to find capacitance it divides charge by voltage; to find voltage it divides charge by capacitance. The stored energy comes from E = ½ × C × V². Every figure is for one settled voltage rather than a changing one.

How the Capacitor Charge Method Works

The method is the ideal capacitor relationship, Q = C × V. Charge is proportional to both capacitance and voltage, so doubling either one doubles the stored charge. The calculator applies this relationship and its rearrangements to whichever pair of values you supply.

• To find charge, it multiplies capacitance by voltage: Q = C × V.
• To find capacitance, it divides charge by voltage: C = Q / V.
• To find voltage, it divides charge by capacitance: V = Q / C.
• In every mode it also returns the stored energy, E = ½ × C × V².
• Values are converted to base units (farads, volts, coulombs) before the math, then shown back in the units you picked.

The result describes the capacitor at one fixed voltage. It is an ideal-model figure, so a real part with manufacturing tolerance can hold a little more or less than the number shown. Use the result as a clean design estimate and confirm against your component’s datasheet.

Capacitor Charge Formulas & Derivations

These are the equations the calculator uses, with the variables named so you can match them to the fields. There is one core relationship, three ways to rearrange it, and the energy expression.

• Charge from capacitance and voltage:

  Q = C × V. Variables: Q is charge in coulombs, C is capacitance in farads, V is voltage in volts.

• Capacitance from charge and voltage:

  C = Q / V. The same relationship solved for C. Voltage must not be zero.

• Voltage from charge and capacitance:

  V = Q / C. The same relationship solved for V. Capacitance must be greater than zero.

• Energy stored in the capacitor:

  E = ½ × C × V², with E in joules. The tool reports this in every mode once it knows C and V.

  Derivation sketch: energy is the work done moving charge onto the plates, the integral of V with respect to q. With V = q / C, that integral from 0 to Q gives Q² / (2C), which equals ½ × C × V².

That single relationship, Q = C × V, together with the energy expression, covers everything this calculator computes. They describe the charge and energy a capacitor holds at a steady voltage, which is what the tool is built to report.

Inputs and Assumptions for Capacitor Charge

Set the calculation up with a few clear inputs. The tool reads your entries as the variables in Q = C × V and applies the unit you choose for each one.

• Capacitance C: the rated or measured value, in F, mF, µF, nF, or pF.
• Voltage V: the voltage across the capacitor, in V, mV, or kV.
• Charge Q (optional): the charge on the plates, in C, mC, µC, or nC. Enter this only when you are solving for capacitance or voltage.
• Solve For: choose whether to calculate charge, capacitance, or voltage from the other two.

The tool assumes an ideal capacitor at a single steady voltage. It does not account for the part’s tolerance, its voltage rating, or how the charge builds up while a circuit is switched on. Keep voltages within the capacitor’s rated limit, and remember that a charged capacitor can hold a dangerous amount of energy even after the supply is removed.

How to Use the Capacitor Charge Calculator (Steps)

Here’s a concise overview before we dive into the key points:

1. Choose what to solve for: charge Q, capacitance C, or voltage V.
2. Enter capacitance C and choose its unit (F, mF, µF, nF, or pF).
3. Enter voltage V and choose its unit (V, mV, or kV).
4. When solving for capacitance or voltage, enter the known charge Q and its unit (C, mC, µC, or nC) instead.
5. Click Calculate to read the solved value along with the stored energy.
6. Switch the Solve For menu to rework the same numbers a different way.

These points provide quick orientation—use them alongside the full explanations in this page.

Example Scenarios

Solve for charge, with a high-voltage warning: a power-supply bulk capacitor is C = 470 µF held at V = 400 V. With Solve For set to charge, the tool returns Q = 188 mC and stored energy E = 37.6 J. What this means: 37.6 J is enough energy to be hazardous, so treat a charged bulk capacitor with care and discharge it safely before handling.

Solve for capacitance: you measured Q = 4.7 mC of charge at V = 10 V and want the capacitance. With Solve For set to capacitance, the tool returns C = 470 µF, with stored energy E = 0.0235 J. What this means: the same Q = C × V relationship, rearranged to C = Q / V, identifies the part from a charge-and-voltage measurement.

Solve for voltage: a 100 µF capacitor holds Q = 1 mC of charge and you want the voltage. With Solve For set to voltage, the tool returns V = 10 V, with stored energy E = 0.005 J. What this means: rearranged to V = Q / C, the tool reads back the voltage that a known charge implies on a known capacitance.

Accuracy & Limitations

The calculator uses the ideal capacitor model. That keeps it fast and clear, but a real part will not match the ideal figure exactly. Use the results as design estimates, and confirm anything safety-critical against your measured components.

• Capacitance tolerance can be ±10% to ±20% or wider, which shifts the real charge and energy by the same proportion.
• The figure is for one steady voltage, so it does not describe how charge or voltage change while a circuit is switched on or off.
• A capacitor’s value can drift with temperature, age, and applied voltage, so the rated value is a starting point, not a guarantee.
• Stored energy grows with the square of voltage, so a modest voltage increase raises the hazard sharply.
• Always stay within the capacitor’s voltage rating, and discharge a charged capacitor safely before handling it.

If your project is sensitive, measure the actual capacitance and voltage and re-run the numbers. The relationship Q = C × V holds for the ideal model; the gap you see in practice comes from the real part, not the arithmetic.

Units Reference

Correct units keep calculations consistent and safe. Capacitor charge problems involve charge, capacitance, voltage, and energy. The table below lists the standard SI units used in the formula and this Calculator.

Use metric prefixes to match your parts: µF for microfarads and nF for nanofarads on capacitance, mV or kV on voltage, and µC or nC on charge. Convert to base units before plugging into the manual formula to avoid mistakes.

Tips If Results Look Off

Strange numbers usually trace back to a unit selection or the wrong Solve For choice. Double-check each entry and confirm which value you asked the tool to calculate. A quick mental estimate of Q = C × V is a good sanity check.

• Check each dropdown: 100 µF is very different from 100 mF or 100 nF.
• Make sure Solve For matches the value you left blank, not one you already entered.
• When solving for capacitance, voltage must not be zero; when solving for voltage, capacitance must be greater than zero.
• Sanity-check against Q = C × V: scaling capacitance or voltage up should scale charge up by the same factor.
• Watch the energy figure: because E = ½ × C × V², raising the voltage has an outsized effect.

If the tool still disagrees with a bench measurement, re-measure the actual capacitance and voltage and enter those. Most differences come from a part’s real value differing from its rating, not from the calculation.

FAQ about Capacitor Charge Calculator

How do I calculate the charge stored on a capacitor?

Enter the capacitance and the voltage, leave Solve For on charge, and the calculator multiplies them: Q = C × V. It also reports the stored energy. For example, 470 µF at 400 V gives 188 mC and 37.6 J.

Can it solve for capacitance or voltage instead of charge?

Yes. Set Solve For to capacitance or voltage and enter the charge plus the one other value you know. The tool rearranges the same relationship to C = Q / V or V = Q / C.

How much energy does a charged capacitor store?

The calculator reports stored energy as E = ½ × C × V², in joules, in every mode. Energy rises with the square of voltage, so a charged high-voltage capacitor can hold a hazardous amount of energy even after the supply is removed.

Does this calculator show how long a capacitor takes to charge?

No. It gives the charge and energy a capacitor holds at a steady voltage, not how long charging takes or how the voltage rises while a circuit is on. That timing depends on the rest of the circuit and is outside this tool’s scope.

Key Terms in Capacitor Charge

Capacitance

The measure of how much charge a capacitor stores per volt applied. Higher capacitance means more charge at the same voltage.

Charge

The amount of electric quantity stored, measured in coulombs. It equals capacitance times voltage in an ideal capacitor.

Voltage

The electrical potential difference across the capacitor’s plates, measured in volts. For a fixed capacitance, higher voltage means more stored charge.

Farad (F)

The SI unit of capacitance. One farad holds one coulomb of charge per volt applied. Real parts are usually rated in microfarads, nanofarads, or picofarads.

Coulomb (C)

The SI unit of electric charge. On a capacitor it equals the capacitance in farads times the voltage in volts.

Ideal Capacitor Model

The simplifying assumption behind this tool: charge follows Q = C × V exactly, with no losses, at a single steady voltage.

Solve For

The menu that chooses which value the calculator computes, charge, capacitance, or voltage, from the other two.

Energy Storage

The energy held in a charged capacitor. It equals one half times capacitance times voltage squared.
