Deaerator Vent Rate Calculator

The Deaerator Vent Rate Calculator estimates required steam vent rate to remove dissolved gases from feedwater based on operating conditions.

About the Deaerator Vent Rate Calculator

This tool estimates the vent stream required to expel noncondensable gases from a tray or spray-type deaerator. It starts with your feedwater flow, dissolved oxygen levels, and operating pressure or saturation temperature. It then models how much air-equivalent gas must leave, and how much steam must accompany it.

We use a physics-based approach built on variables you control and constants from steam tables. The method includes an ideal-gas derivation for noncondensables and a practical minimum vent fraction. The result is a recommended vent rate, plus checks against typical practice ranges.

Use it when designing a new unit, auditing an existing system, or troubleshooting oxygen excursions. The calculator is fast to iterate, so you can test scenarios and see the effect of each assumption.

Formulas for Deaerator Vent Rate

The model balances noncondensable gas removal with a small, continuous steam vent. It converts dissolved oxygen removal to a molar gas flow and scales the vent so noncondensables remain a small fraction of the vent stream.

• Oxygen removal, mass rate: m_O2,removed = (C_O2,in − C_O2,out) × m_fw × 1e−6, where C in mg/L and m_fw in kg/s (≈ L/s).
• Molar oxygen removal: n_O2 = m_O2,removed / M_O2, with M_O2 = 32 kg/kmol.
• Co-removed nitrogen (air basis): n_N2 ≈ n_O2 × 79/21 = 3.76 × n_O2; add CO2 if measured: n_CO2 = m_CO2 / M_CO2.
• Total noncondensable molar flow: n_nc = n_O2 + n_N2 + n_CO2.
• Target vent composition: choose y_nc (mole fraction noncondensables in the vent, often 0.01–0.05). Then n_vent = n_nc / y_nc.
• Vent mass flow: m_vent ≈ n_vent × (y_nc × M_nc + (1 − y_nc) × M_w), with M_nc ≈ 29 kg/kmol (air) and M_w = 18 kg/kmol.

We also apply a practical minimum: m_vent ≥ f_min × m_fw, where f_min commonly ranges 0.001–0.005 (0.1–0.5% of feedwater). If plant practice uses a steam-based baseline, you may instead set m_vent ≥ f_min,steam × m_steam, where m_steam is the heating/stripping steam to the deaerator.

How the Deaerator Vent Rate Method Works

The method starts with a mass balance for oxygen and associated air. Dissolved oxygen removed from the liquid must leave in the vent as gas. Because pure air does not flow alone, a small amount of saturated steam carries it out.

• Convert dissolved oxygen removal to molar flow using molar mass and the feedwater rate.
• Estimate accompanying nitrogen and carbon dioxide based on air composition or measurements.
• Choose a safe noncondensable fraction y_nc for the vent. Lower y_nc increases steam sweep and stripping.
• Compute the required total vent flow so noncondensables meet the y_nc target.
• Apply the minimum vent fraction to ensure stable operation under low-load or low-O2 conditions.

At operating pressure, the vent gas is near saturation temperature, so we treat the steam portion as saturated vapor. We use the ideal gas law for noncondensables and standard molar masses. This derivation keeps constants and variables explicit, so you can audit each step.

Inputs, Assumptions & Parameters

Provide a few measured values and choose reasonable defaults. The calculator blends data, physics, and industry heuristics to derive a reliable vent rate.

• Feedwater mass flow, m_fw (kg/s or lb/h).
• Inlet and target dissolved oxygen, C_O2,in and C_O2,out (mg/L or ppb).
• Deaerator operating pressure or saturation temperature (kPa or °F/°C).
• Target vent noncondensable fraction, y_nc (typical 0.01–0.05).
• Minimum vent fraction, f_min, as a percent of m_fw or m_steam.
• Optional CO2 or total dissolved gases, if measured (mg/L).

Assume water density ≈ 1 kg/L near saturation for the ppm-to-mass conversion. Use ideal gas behavior for noncondensables and saturated steam properties at operating pressure. Edge cases include near-vacuum operation, very high CO2, or oxygen below sensor detection limits; in those cases, the minimum vent policy often governs.

How to Use the Deaerator Vent Rate Calculator (Steps)

Here’s a concise overview before we dive into the key points:

1. Enter the feedwater mass flow at the deaerator outlet.
2. Enter the deaerator pressure or its saturation temperature.
3. Enter inlet dissolved oxygen and your target outlet oxygen.
4. Set a target noncondensable mole fraction in the vent (y_nc).
5. Choose a minimum vent fraction to enforce good stripping.
6. Click Calculate to view the recommended vent mass and volumetric rates.

These points provide quick orientation—use them alongside the full explanations in this page.

Case Studies

A 50,000 lb/h feedwater system (≈6.3 kg/s) runs at 0.2 MPa abs, near 120°C. Inlet oxygen is 8 mg/L; the target is 7 ppb. The model removes about 7.993 mg/L, giving n_O2 ≈ 1.57×10⁻⁶ kmol/s and n_N2 ≈ 5.90×10⁻⁶ kmol/s. Total noncondensables n_nc ≈ 7.47×10⁻⁶ kmol/s. With y_nc = 0.02, n_vent ≈ 3.74×10⁻⁴ kmol/s; m_vent ≈ 0.0068 kg/s (≈24.5 kg/h), roughly 0.11% of feedwater. What this means: The vent falls within common guidance and supports deep oxygen removal without excessive steam loss.

A smaller unit at 1.5 kg/s and 0.1 MPa abs sees 10 mg/L inlet oxygen and targets 20 ppb. The model removes 9.98 mg/L, yielding n_O2 ≈ 4.68×10⁻⁷ kmol/s and n_N2 ≈ 1.76×10⁻⁶ kmol/s; n_nc ≈ 2.23×10⁻⁶ kmol/s. With y_nc = 0.03, n_vent ≈ 7.43×10⁻⁵ kmol/s and m_vent ≈ 0.00136 kg/s (≈4.9 kg/h), which is only ≈0.09% of feedwater. Applying a minimum vent fraction of 0.15% raises the recommended vent to ≈0.00225 kg/s (≈8.1 kg/h). What this means: Under light loads or clean water, the minimum vent rule dominates to keep stripping reliable.

Limits of the Deaerator Vent Rate Approach

This approach captures the main physics and the practical minimum vent policy, but every plant is different. Internal tray design, spray patterns, and steam distribution affect gas removal efficiency. Instrument accuracy also matters at ppb oxygen levels.

• Non-ideal mixing or short-circuiting can increase required vent rates.
• CO2 release from bicarbonate alkalinity may exceed air-based estimates.
• Vacuum deaeration or very low pressure requires care with density and vent sizing.
• Sensor limits below 5–10 ppb can mask real variability in oxygen removal.

Use this calculator to set a starting target, then confirm with field tests. Check oxygen downstream of the deaerator and at boiler economizer outlets during load swings.

Units and Symbols

Units matter because small changes in concentration can shift vent sizing. Keep molar masses, the ideal gas constant, and saturation conditions consistent. The table below lists common variables and units used in the derivation.

Read the table left to right and keep units consistent. For example, if you use kPa and kmol, use R in kPa·m³/(kmol·K). If you switch to psi and lbmol, convert all constants and variables accordingly.

Tips If Results Look Off

If your vent rate seems too high or low, check units and a few sensitive inputs first. Small errors in oxygen ppm can shift results a lot. Pressure and temperature must reflect the actual operating point, not nameplate data.

• Verify oxygen units (mg/L vs ppb) and meter calibration.
• Confirm deaerator pressure with a calibrated gauge or transmitter.
• Try y_nc between 0.01 and 0.05 and see the effect on ṁ_vent.
• Test the minimum vent fraction at 0.1%, 0.25%, and 0.5%.

If numbers still diverge from field data, sample for CO2 and total dissolved gases, and inspect trays, spray valves, and vent piping for restrictions.

FAQ about Deaerator Vent Rate Calculator

What is a typical vent rate for a well-tuned deaerator?

Most plants run between 0.1% and 0.5% of feedwater or stripping steam. The exact value depends on oxygen load, pressure, and internals.

How does vent noncondensable fraction y_nc affect steam loss?

Lower y_nc means cleaner vent gas but more steam. Raising y_nc reduces steam loss but risks gas buildup and higher outlet oxygen.

Can I model CO2 separately from air?

Yes. Enter CO2 if measured. The calculator converts it to molar flow and adds it to oxygen and nitrogen to size the total vent.

What if my measured oxygen is below the sensor limit?

Use the minimum vent fraction to maintain stripping. Then confirm with periodic laboratory samples or an instrument with lower detection limits.

Glossary for Deaerator Vent Rate

Deaerator

A vessel that heats and strips dissolved gases from boiler feedwater using steam at or near saturation conditions.

Noncondensables

Gases like oxygen, nitrogen, and carbon dioxide that do not condense at deaerator conditions and must be vented.

Mole Fraction

The ratio of moles of a component to total moles in a mixture, used here to control vent composition.

Ideal Gas Law

A relation among pressure, volume, temperature, and moles (PV = nRT) used for noncondensable gases in the vent.

Molar Mass

Mass per mole of a substance, such as 18 kg/kmol for water vapor and about 29 kg/kmol for air.

ppb and ppm

Parts per billion and parts per million. In water, mg/L ≈ ppm by mass near room temperature.

Stripping Steam

Saturated steam used to heat water to saturation and sweep out dissolved gases in a deaerator.

Minimum Vent Fraction

A practical lower bound on vent rate to ensure stable gas removal when oxygen loading is low.
